Multi-functional servo regulator RBD-S+

About

The RBD-S+ offers solutions for multifunctional applications in plant engineering; it can be used either as torque-, speed- or positioning controller, and can optionally be operated with or without a superordinate SPS.

Specification

Power Supply : 24 VDC
Safety function: STO
Access: 6 digital, 1 analogue
Outlets: 4 digitals, 2 analogue (-10...+10 V)
Holding Brake: 24 V; 2 A
Encoder: Absolute Encoder (Hyperface, EnData), Resolver, SinCos
Interface : 1x USB, 1x CAN, Ethernet
Operating Voltage: 230 VAC
Ambient temperature: 40°C max.
Nominal Output : 800 VAC
Output max. for 2 s: 2,000 VAC

GroMoC

With this application, you can put your Groschopp drives into operation quickly, safely and easily. The application allows you to have a real-time view of your controller.

About

Control your Groschopp drives as mobile as possible. With this application, you can put your Groschopp drives into operation quickly, safely and easily.

Monitoring

Observe and check the progress, quality and state of motor that is working over a different time periods, using manual or automatic mode.

Command mode

Operate the motor in different modes (Velocity, Current and Position ) by sending information directly from the app.

Ramps and limits

Ramps - Setting the acceleration for positive and negative directions. Limits - Here you can set the boundary value of the selected mode.

Motors

AC-MOTORS

Typical induction motors are suitable for both three-phase and single-phase current. Motors have a fixed speed, either 1,400 min-1 (4-pole) or 2,800 min-1 (2-pole).Typical induction motors are suitable for both three-phase and single-phase current. Motors have a fixed speed, either 1,400 min-1 (4-pole) or 2,800 min-1 (2-pole).

DC-MOTORS

DC-Motors are used in industry, automobiles and households. Almost every food processor and every electrical tool is equipped with DC-drives.DC-Motors are used in industry, automobiles and households. Almost every food processor and every electrical tool is equipped with DC-drives.

SERVO-MOTORS

“Black Panther” is an electronically-commutated servo-motor of the third generation. Through continually optimizing the active core-elements (stator, rotor, magnets) and using a modern winding around single teeth, the power density could be increased by a factor 2 to 3 compared to conventional High-End-servo-motors.
